APT 320XAC - Page 30

24
OPTIONS
310XAC
320XAC
340XAC
360XAC
Grounded Neutral
Option
2
All Models
GPIB Card
Option
3
All Models
7 Remote Memories
Select
Option
4
Input (Test, Reset, Recall Memory 1 - 7)
Ethernet/RS-
232/Barcode
Option
5
All Models
Linking Card
Option
8
All Models
LINKING PARALLEL AC OUTPUT
1Φ2W
310XAC
320XAC
340XAC
360XAC
Linked Units
2 - 3 Units, 1Φ2W (L1 - N )
Voltage
Phase
5 - 300 V
5 - 300 V
Power
# Units
2
1.8 KVA
3.6 KVA
7.2 KVA
10.8 KVA
Max
3
2.7 KVA
5.4 KVA
10.8 KVA
16.2 KVA
Max Current
5 - 150 V
L(2)
14.72 A @ > 20 V
and < 120 V
29.44 A @ > 20 V
and < 120 V
58.88 A @ > 20 V
and < 120 V
88.32 A @ > 20 V
and < 120 V
L(3)
22.08 A @ > 20 V
and < 120 V
44.16 A @ > 20 V
and < 120 V
88.20 A @ > 20 V
and < 120 V
132.48 A @ > 20 V
and < 120 V
5 - 300 V
H(2)
7.36 A @ > 20 V
and < 240 V
14.72 A @ > 20 V
and < 240 V
29.44 A @ > 20 V
and < 240 V
44.16 A @ > 20 V
and < 240 V
Line
H(3)
11.04 A @ > 20 V
and < 240 V
22.08 A @ > 20 V
and < 240 V
44.16 A @ > 20 V
and < 240 V
66.24 A @ > 20 V
and < 240 V
LINKING POLY-PHASE AC OUTPUT
1Φ3W
310XAC
320XAC
340XAC
360XAC
Linked Units
2 Units @ 180º, 1Φ3W (L1-L2 - N)
Voltage
Phase
10 - 600 V
10 - 600 V
Line
5 - 300 V
5 - 300 V
Power
Max
2 KVA
4 KVA
8 KVA
12 KVA
Max Current
5 - 300 V
L(1)
9.2 A @ 100 V
18.4 A @ 110 V
36.8 A @ 110 V
55.2 A @ 110 V
Phase
5 - 600 V
H(1)
4.6 A @ 220 V
9.2 A @ 220 V
18.4 A @ 220 V
27.6 A @ 220 V
Max Current
5 - 300 V
L(2)
9.2 A @ 220 V
18.4 A @ 220 V
36.8 A @ 220 V
55.2 A @ 220 V
Line
5 - 600 V
H(2)
4.6 A @ 440 V
9.2 A @ 440 V
18.4 A @ 440 V
27.6 A @ 440 V
LINKING POLY-PHASE AC OUTPUT
3Φ4W
310XAC
320XAC
340XAC
360XAC
Linked Units
3 Units @ 120º, 3Φ4W (L1-L2-L3 - N)
Voltage
Phase
5 - 300 V
5 - 300 V
Line
5 - 520 V
5 - 520 V
Power
Max
3 KVA
6 KVA
12 KVA
18 KVA
Max Current
5 - 150 V
L(1)
9.2 A @ 110 V
18.4 A @ 110 V
36.8 A @ 110 V
55.2 A @ 110 V
Phase
5 - 300 V
H(1)
4.6 A @ 220 V
9.2 A @ 220 V
18.4 A @ 220 V
27.6 A @220 V
Max Current
5 - 150 V
L(3)
9.2 A @ 190.5 V
18.4 A @ 190.5 V
36.8 A @ 190.5 V
55.2 A @ 190.5 V
Line
5 - 300 V
H(3)
4.6 A @ 381 V
9.2 A @ 381 V
18.4 A @ 381 V
27.6 A @381 V
Max Current
5 - 260 V
L(3)
5.31 A @ 190.5 V
10.62 A @ 190.5
V
21.24 A @ 190.5 V
31.87 A @ 190.5 V
Phase Delta
5 - 520 V
H(3)
2.65 A @ 381 V
5.31 A @ 381 V
10.62 A @ 381 V
15.93 A @ 381 V
