APT 320XAC - Page 32

26
MEASUREMENT (Total)
LINKING PARALLEL 1Φ2W
310XAC
320XAC
340XAC
360XAC
Power Reactive (Q)
Range
2
0 W - 2600 VAR
0 W - 25200
VAR
0 W -10400 VAR
0 W - 15600 VAR
3
0 W - 3900 VAR
0 W - 7800 VAR
0 W - 15600 VAR
0 W - 23400 VAR
Resolution
1 VAR
Accuracy
√(VA)² - (W)², Calculated Value
MEASUREMENT (Total)
LINKING PARALLEL 1Φ2W
Cont.
310XAC
320XAC
340XAC
360XAC
Power Factor
Range
0 - 1.000
Resolution
0.001
Accuracy
W / VA, Calculated and displayed to three significant digits
MEASUREMENT (Total)
LINKING POLY-PHASE 1Φ3W
310XAC
320XAC
340XAC
360XAC
Voltage
Range
2
L1 Voltage + L2 Voltage
Resolution
0.1 V
Accuracy
Summation of linked sources, Calculated and displayed to one significant digit
Frequency
Range
0.0 - 1000.0 Hz
Resolution
0.1 Hz
Accuracy
L
± 0.1 Hz @ 0.0 - 500 Hz
H
± 0.2 Hz @ 501 - 1000 Hz
Current (rms)
Range
2
(L1 Current + L2 Current)/2
Resolution
L
0.001 A
X
X
H
0.01 A
Accuracy
± (1% of reading +5counts) at 40~70Hz
± (1% of reading +5counts) at 70.1~500Hz, and output current (r.m.s) > 0.200A
± (1% of reading +5counts) at 501~1000Hz, and output current (r.m.s) > 0.300A
Power (W)
Range
2
L1 Power + L2 Power
Resolution
L
0.1 W
X
X
H
1 W
Accuracy
2
L1 Power + L2 Power, Calculated Value
Power Apparent (VA)
Range
2
L1 VA + L2 VA
Resolution
L
0.1 VA
X
X
H
1 VA
Accuracy
2
L1 VA + L2 VA, Calculated Value
Power Reactive (Q)
Range
2
L1 VAR + L2 VAR
Resolution
L
0.1 VAR
X
H
1 VAR
Accuracy
2
L1 VAR + L2 VAR, Calculated Value
Power Factor
Range
0 - 1.000
Resolution
0.001
Accuracy
(L1 P + L2 P) / (L1 VA + L2 VA), Calculated and displayed to three significant digits
