User Manual – Electric Vehicle Charging Equipment IC-CPD
3
Version 1.0 / 1906 Version 1.0 / 1906
A
Vehicle charging inlet
B
Vehicle connector ( page 11)
C
Control box (ICCB)
D
AC power cable
E
Power plug
F
Grid socket
G
Front display with LEDs ( page 14)
H
Back label ( page 17)
CHARGING
TEMPERATURE
POWER
FAULT
2. IC-CPD Overview
For the definition of the individual system
components refer to the overview below.
A
IC-CPD
(In-Cable Control- and Protection Device)
B
C
D
E
F
G H
POWER
CHARGING
FAULT
TEMPERATURE
