User Manual – Electric Vehicle Charging Equipment IC-CPD
14
Version 1.0 / 1906
The front panel of the IC-CPD is equipped with four
indicator lights:
1. POWER is illuminated:
Electricity from the grid is on and the
IC-CPD is ready for use
2. CHARGING flashing:
A flashing light indicates that energy is
delivered to the vehicle
3. TEMPERATURE is illuminated:
The internal temperature exceeds a
certain value
4. FAULT flashing red:
Shows a failure of the charging system
According to the operating mode, the IC-CPD charging
equipment emits different combinations of continuously
illuminated and/or flashing LEDs.
(For additional explanations, see page 17)
10. Front display of the ICCB
POWER
CHARGING
FAULT
TEMPERATURE
