Aptiv IC-CPD - Handling and Usage Guidance Pictograms

User Manual – Electric Vehicle Charging Equipment IC-CPD
5
Version 1.0 / 1906 Version 1.0 / 1906
Instruction:
Follow instructions
Warning:
Electric voltage
Warning:
Hot surface
Warning:
Obstacles on the ground
Prohibition:
No direct sunlight,
no direct cover
Prohibition:
Do not kink the cable
Pictograms
Prohibition:
Do not run over plug,
control box and cables
Prohibition:
Do not use the IC-CPD
if it is damaged
Prohibition:
Do not unplug the power plug
during the charging process
Prohibition: Do not carry out
repairs on the IC-CPD
and do not open it
Prohibition:
No multiple sockets
and adapters
Prohibition:
No contact with snow
or ice
Prohibition:
No extension cables
Prohibition: Do not immerse in
water, do not expose to a direct jet
of water or splash water
Temperature range for start-up
Prohibition:
Do not use
the charging equipment
with coiled up cables
3. Used warnings, symbols and pictograms
Handle with care
Instruction:
Handle charging device with care
