Aquatic Industries, Inc. 15
INFINITY ON/OFF WITH HEATER CONTROL (SEE DIAGRAM 6A):
1. To Turn Pump On: Pressing the On/Off button will turn the pump on. Pressing a second time will turn the pump
off. A built-in timer will turn the pump and heater off after 20 minutes.
changes the setting continuously. The temperature can vary from 90° to 104° F.
the set point +1° F.
3. For Infinity 1: To Turn Continuous Waterfall On: Pressing and holding down the chromatherapy button for 2
seconds will turn the continuous waterfall on. Depressing the chromatherapy button for 2 seconds with the continuous
waterfall will automatically turn off after 20 minutes. Note: The
continuous waterfall is only featured on the Infinity 1.
Other Features:
and then blanks itself.
temperature for a period of 15 minutes.
of the water at the High-Limit sensor reaches 119° F. Should
be allowed to work. Only the heater will be shut off. In order for
the heater to be reactivated the user must reset circuit breaker
when the temperature has fallen below 119° F.
water temperature reading and the remaining minutes on the timer. This will toggle every 5 seconds.
OPERATION of
INFINITY SERIES WHIRLPOOLS
NOTE: DO NOT START PUMP UNTIL ALL JETS ARE SUBMERGED. WATER LEVEL SHOULD
BE 2” ABOVE HIGHEST JET.
BATHSIDE CONTROL SYSTEMS:
Set Point Indicator
Heater On Indicator
6A
