3.1) Connect the assembled blade fuse adaptor to the
connector on the main patch loom as shown.
3.2) Go to the LH (passenger’s) side of the vehicle.
Open the front and rear doors and remove the
lower scuff plate plastic mouldings by prising them
upwards.
