3.3) Undo the retaining nut on the passenger side front
kick panel and pull the kick panel rearwards, at an
angle towards the foot well, to release the trim
clips.
3.4) Beneath the glove box is a fuse box. If there is a
pair of 10A fuses, remove the lower 10 Amp fuse.
3.5) Insert the loom blade fuse adaptor assembly into
the location where the 10 Amp fuse was removed.
IF THERE ARE NO 10A FUSES, REFER TO
NEXT STEP
IF THERE ARE NO 10A FUSES, REFER TO THIS
STEP. OTHERWISE CONTINUE BELOW.
3.6) Find fuse box above vacant one from above and
remove cover. (place cover in glovebox when
complete as it will no longer fit over fuses)
