3.30) Disconnect the connector on the tail lamp.
3.31) Plug in the brake light patch harness to the tail
lamp and to the vehicle’s connector.
3.32) Thread the free end of the brake light patch loom
with the one blade terminal on the end, down
through the tail light recess following the vehicle’s
loom.
