3.33) Cable tie the loom to the main vehicle loom with
one 200mm long cable tie in the rear lower corner
of the tub underneath.
3.34) Cable tie the loom to the main vehicle loom with
one 200mm long cable tie above the LH chassis
rail, rear of the spare tyre.
3.35) Cable tie the loom to the main vehicle loom with 3
off 200mm long cable ties around the LH rear
shock absorber wiring bracket.
