5. Before final fitting, ensure the arrow on the inside of
the cover is pointing to the rear of the vehicle.
If incorrectly fitted, the centre tab should interfere with
the roof sheet metal panel tab.
6. Place the cover over the cavity and align the mounting
holes to the screw locations in the roof.
7. Press the cover onto the roof to compress the seals
and using the holding screws retained from earlier,
screw the cover down firmly, taking care not to over-
tighten and strip the thread.
