Arbiter Systems 1093B User Manual

7.8 Setting Programmable Pulse Mode 41
7.8.3 Programmable Pulse – Pulse–Per–Hour Mode
Use the “Pulse–Per–Hour” mode to generate a pulse every hour, at the number of specified sec-
onds (from 0 to 3599 seconds) after the hour. Refer to Section 7.8 above for additional detail
on the programmable pulse modes, and entering numerical values. For RS-232 command, see
Section 10.2.12.
SET PROG. PULSE?
ENTER
SETUP
PROG. PULSE MODE?
PULSE PER HOUR?
DOWN
UP
SET PULSE WIDTH?
PULSE WIDTH = 000.01
600.00
|
000.01*
SET SEC. AFTER HOUR?
3599 SEC.
3599*
|
0000
SELECT UTC OR LOCAL?
PULSE TIME = UTC
LCL
UTC*
* = Default Setting
(-) POLARITY?
(+) POLARITY?
SLOW CODE LCL?
SLOW CODE UTC?
SINGLE TRIGGER?
PULSE PER DAY?
PULSE PER HOUR?
SEC. PER PULSE? *
ENTER
ENTER
ENTER
ENTER
DOWN
UP
DOWN
UP
DOWN
UP
Figure 7.11: Pulse–Per–Hour Setup
