ARCA LS100 - Functional Groups and Position; External Parts and Connectors

Operator Manual
LS100
8
Functional groups and their position
External parts and connector panel
1 - Magnetic Card Reader
2 - LED
1
3 - Document Path
4 - Adjustable Stop of the Document
5 - Document Holder
2
6 - Document Recovery bin
7 – Serial Interface (Factory use only)
3
8 - USB Connector
9 - Power Connector
10 - ON/OFF Switch
11 - Data Label
5
6
4
11
7 8 9 10
