AVR300 SURROUND SOUND RECEIVER
- 48 -
VIDEO BOARD
U813: TA1270BF
-INPUT B
V
CC
OUTPUT B
+INPUT B
-INPUT A
OUTPUT A
+INPUT A
V
EE
VIDEO BOARD
U819, U820, U823: TK15420M
GND
IN1
IN2
IN3
OUT1
OUT2
OUT3
V
CC
1
2
3
4
8
7
6
5
75W
driver
75W
driver
75W
driver
VIDEO BOARD
U806, U807, U811, U814-U817, U821: BA7623
