AVR300 SURROUND SOUND RECEIVER
- 82 -
EXPLODED VIEW PARTS LIST
0101 *CE BLACK / UL BLACK 1403-6244-0 FRONT PANEL BLACK AVR300
0101 *CE SILVER / UL SILVER 1403-6245-0 FRONT PANEL SILVER
0102 *CE SILVER / UL SILVER 1405-1002-0 TOP COVER SILVER AVR300
0102 *CE BLACK / UL BLACK 1405-1001-0 TOP COVER BLACK AVR300
0103 1403-6261-0 FRONT BRACKET AVR300
0104 1405-1101-0 CHASSIS AVR300
0105 1405-0901-0 REAR PANEL AVR300
0106 4135-4101-0 PHONE BRACKET AVR300
0107 4135-4051-0 TRANSFORMER BRACKET
0108 2446-6601-0 BASS AND TREBLE KNOB
0109 4134-2820-0 VOLUME KNOB
0110 *CE SILVER / UL SILVER 4134-2831-0 END CAP (LEFT)
0110 *CE BLACK / UL BLACK 4134-2830-0 FRONT ORNAMENT (LEFT)
0111 *CE SILVER / UL SILVER 4134-2841-0 END CAP (RIGHT)
0111 *CE BLACK / UL BLACK 4134-2840-0 FRONT ORNAMENT (RIGHT)
0112 4135-4071-0 POWER BRACKET AVR300
0113 4152-0451-0 L-BRACKET
0114 4152-4631-0 RUBBER FOOT (522) 14MM
0115 8901-4500-0 POWER LED LENS W/LIGHT
0116 4152-7522-0 LENS AVR300
0117 4152-7531-0 TUNER KNOBS
0118 4152-7560-0 VOLUME KNOB HOLDER
0119 2446-6501-0 FONCTION KNOBS AVR300
0121 4152-4641-1 CUSHION FOOT W/RUBBER WA
0122 4154-1502-0 POWER KNOB
0123 4134-9071-0 BRACKET PCB MOUNTING
0124 4135-4091-0 HEATSINK BRK2 AVR300
0125 3716-9906-0 LED POST AVR300
0126 4135-4081-0 HEATSINK BRK1 AVR300
0127 5400-3852-0 HEATSINK RIGHT AVR300
0128 5400-3851-0 HEATSINK LEFT AVR300
0129 4135-4061-0 LONG BRACKET AVR300
0130 4157-0611-0 TRANSFORMER RUBBER PAD
0131 4135-0942-0 TRANSFORMER STEEL COVER
Reference No. Part No. Description
