Arcam AVR300 Service Manual

- 51 -
AVR300 SURROUND SOUND RECEIVER
POWER AMP1 ASSY
PC BOARD
PCB-AL050C-AMP1 PCB ASSY POWER AMP1
CAPACITORS
C412,C512,C612,C712 150F-332K-2-FD CC 50V 3300P 10% AT
C407,C507,C607,C707 153F-101K-5-MKN CM 100PF 50V RL (7X6)
C402,C502,C602,C702 153H-471J-9-NLV CM 100V 470P 5% RB
C121,C231,C341,C441,C541,C641,C741 153I-102J-9-NL CM 63V 0.001uF 5% RB 7.5
C808 157D-107M-K-IUI CE 16V 100UF 20% RLT
C801,C802,C803,C809 157D-107M-K-LUTI CE 16V 100U 20% RLT
C405,C505,C605,C705,C813 157D-227M-K-OVY CE 16V 220U 20% RLT
C406,C408,C411,C506,C508,C511,C606,
C608,C611,C706,C708,C711
157F-106M-K-IUTI CE 50V 10U 20% RLT 5X11
C409,C410,C509,C510,C609,C610,C709, C710 157F-475M-K-IUTI CE 50V 4.7U 20% RLT 5X11
C806,C807 157I-227M-K-S9TI CE 63V 220U 20% RLT
C403,C404,C503,C504,C603,C604,C703, C704 157I-476M-K-OVTI CE 63V 47U 20% RLT
C401,C501,C601,C701 157Q-106M-K-IUE CE 35V 10U 20% 5X11 RLT
DIODES
D403,D404,D503,D504,D603,D604,D703,
D704,D802,D803,D805
4804-0040-2 DIODE IN4004 AT
D401,D402,D501,D502,D601,D602,D701,D702,
D801,D804,D806,D807,D808
4804-1480-3 DIODE LL4148 SM
Z802 4837-10D1-2 DZ 1/2W 9.94~10.44V ROHM
Z401,Z402,Z501,Z502,Z601,Z602,Z701,Z702 4837-27V0-2 DZ 1/2W 27V(26.2-27.6)AT
Z804 4837-5B61-2 DZ 1/2W 5.45-5.73 ROHM
WAFERS/SOCKETS
P107A 2101-1801-0 SOCKET (PCB/PCB) 10P
P106A 2102-061S-004 6P ST. WAFER
P104A1 2102-081S-004 WAFER 8P P2.5 ST.
JACKS/SOCKETS
P401,P501,P601,P701 2113-1160-0 WAFER 2P ST. P=2.5 NH
TRANSISTOR
Q401,Q501,Q601,Q701 4851-241A-5 TR RN1241-A
Q417,Q517,Q617,Q717 485A-1930-5 TR 2SA1930 HFE 100-320
Q409,Q410,Q509,Q510,Q609,Q610,Q709, Q710 485A-949O-5 TR 2SA949-O HFE 70-140
Q802 485B-772P-5 TR 2SB772P PNP POWER TR
Q810,Q811,Q812 485C-114E-5 TR DTC114ES
Q801,Q803,Q804,Q805,Q806 485C-123J-5 TR DTC123JSA ROHM
Q412,Q512,Q612,Q712 485C-2229-5 TR 2SC2229-0 HFE 70-140
Reference No. Part No. Description
ELECTRONICS PART LIST
