Arcam AVR300 Service Manual

AVR300 SURROUND SOUND RECEIVER
- 52 -
Q416,Q516,Q616,Q716 485C-5171-5 TR 2SC5171 HFE 100-320
Q404,Q405,Q406,Q407,Q411,Q414,Q420, Q504,
Q505,Q506,Q507,Q511,Q514,Q520, Q604,Q605,
Q606,Q607,Q611,Q614,Q620, Q704,Q705,Q706,
Q707,Q711,Q714,Q720
4860-0190-5 TR 2SC 1845 (F.E) RL
Q402,Q403,Q408,Q415,Q502,Q503,Q508, Q515,
Q602,Q603,Q608,Q615,Q702,Q703,Q708, Q715,
Q809
4860-0660-5 TR 2SA1015 (G.R.) RL
Q413,Q513,Q613,Q713 4860-1220-5 TR 2SC3421 (0,Y) RL TSB
Q419,Q519,Q619,Q719 4860-3420-5 TR 2SA1987 TO-39 PNP
Q418,Q518,Q618,Q718 4860-3430-5 TR 2SC5359 TO-3P NPN
RESISTOR
R809 4711-103A-2 RMF 1/8W 10K 1% AT
R402,R412,R502,R512,R602,R612,R702, R712 4711-223A-2 RMF 1/8W 22K 1% AT
R807 4718-391J-2-X RMF 1W 390R 5% AT
R425,R430,R525,R530,R625,R630,R725, R730 4715-822A-2 RMF 1/4W 8.2K 1% AT
R820 4718-010J-L-X RMF 1W 1R 5% AF METAL
R421,R422,R521,R522,R621,R622,R721, R722 4718-100J-2 RMF 1W 10R 5% AT
R437,R537,R637,R737 4718-101J-2-X RMF 1W 100R 5% AT METAL
R403,R404,R503,R504,R603,R604,R703, R704 4720-101A-J RMG 1/10W 100R 1% 0805
R411,R414,R431,R432,R511,R514,R531,
R532, R611,R614,R631,R632,R711,R714,
R731,R732,R822
4720-102J-J RMG 1/10W 1K 5% 0805
R187,R444,R445,R544,R545,R644,R645,R744,
R745,R801,R808,R810,R811
4720-103J-J RMG 1/10W 10K 5% 0805
R413,R513,R613,R713 4720-123J-J RMG 1/10W 12K 5% 0805
R804,R805 4720-152J-J RMG 1/10W 1.5K 5% 0805
R420,R520,R620,R720 4720-180J-J RMG 1/10W 18R 5% 0805
R427,R428,R527,R528,R627,R628,R727, R728 4720-181J-J RMG 1/10W 180R 5% 0805
R818 4720-201J-J RMG 1/10W 200R 5% 0805
R407,R507,R607,R707 4720-221J-J RMG 1/10W 220R 5% 0805
R418,R433,R434,R518,R533,R534,R618, R633,
R634,R718,R733,R734
4720-222J-J RMG 1/10W 2.2K 5% 0805
R409,R416,R442,R509,R516,R542,R609, R616,
R642,R709,R716,R742
4720-223A-J RMG 1/10W 22K 1% 0805
R443,R543,R643,R743 4720-223J-J RMG 1/10W 22K 5% 0805
R415,R515,R615,R715 4720-270J-J RMG 1/10W 27R 5% 0805
R439,R539,R639,R739 4720-272J-J RMG 1/10W 2.7K 5% 0805
R802 4720-302J-J RMG 1/10W 3K 5% 0805
R188,R441,R541,R641,R741 4720-333J-J RMG 1/10W 33K 5% 0805
R440,R540,R640,R740 4720-471J-J RMG 1/10W 470R 5% 0805
R803,R806,R821,R823 4720-472J-J RMG 1/10W 4.7K 5% 0805
R419,R435,R436,R519,R535,R536,R619, R635,
R636,R719,R735,R736
4720-561J-J RMG 1/10W 560R 5% 0805
R405,R406,R505,R506,R605,R606,R705, R706 4720-680A-J RMG 1/10W 68R 1% 0805
R401,R410,R501,R510,R601,R610,R701, R710 4720-681J-J RMG 1/10W 680R 5% 0805
Reference No. Part No. Description
