Arcam AVR300 Service Manual

- 53 -
AVR300 SURROUND SOUND RECEIVER
R417,R423,R424,R517,R523,R524,R617, R623,
R624,R717,R723,R724
4720-820J-J RMG 1/10W 82R 5% 0805
R408,R426,R429,R508,R526,R529,R608, R626,
R629,R708,R726,R729
4720-822J-J RMG 1/10W 8.2K 5% 0805
R438,R538,R638,R738 474B-R22K-5-02 RWR 5W 0.22R X2 10% RL
IC
U801 3130-2790-1 IC NJM7808FA +8V REG
SEMI FIXED
VR401,VR501,VR601,VR701 4755-4715-3-00 SVR 470R 5X5.6 90DEG
LED
LED101,LED102 3700-2489-G LED 3MM GREEN SP
HEATSINKS
U801C 5400-0831-0 HEATSINK
Q416C,Q417C,Q516C,Q517C,Q616C, Q617C,
Q716C,Q717C
5400-9130-0 HEAT SINK FOR 7805 2438-
WIRE
P104A 7012-6681-0 CONN WIRE 10P P=2.5 6AWG
P109A 7012-6682-0 CONN WIRE 8P P=3.96
P108B 7012-6686-0 CONN WIRE 6P P=2.5 26AWG
JP102A 7012-6766-1 CONN WIRE UL1015 14AWG
SCREW
Q416A,Q417A,Q516A,Q517A,Q616A, Q617A,
Q716A,Q717A,U801A
2954-2606-0000 SCREWS BT 2.6X6
Q416B,Q417B,Q516B,Q517B,Q616B, Q617B,
Q716B,Q717B,U801B
2954-3008-0000 TAPPING 3X8MM B-TITE
PC BOARD
4000 1725-695A-0001 PCB AMP1/AMP2/SW/RECT/
MISCELLANEOUS
SE801 8910-0489-0 THERMISTOR 100C
POWER AMP2 ASSY
PC BOARD
PCB-AL050C-AMP2 PCB ASSY POWER AMP2
CAPACITORS
C112,C212,C312 150F-332K-2-FD CC 50V 3300P 10% AT
C107,C207,C307 153F-101K-5-MKN CM 100PF 50V RL (7X6)
C839,C840 153F-103K-5-LJN CM50V 0.01UF 10% 6.5X5.5
Reference No. Part No. Description
