AVR300 SURROUND SOUND RECEIVER
- 54 -
C102,C202,C302 153H-471J-9-NLV CM 100V 470P 5% RB
C105,C205,C305 157D-227M-K-OVY CE 16V 220U 20% RLT
C838 157E-227M-K-OVI CE 25V 220UF 20% RLT
C106,C108,C111,C206,C208,C211,C306, C308,
C311
157F-106M-K-IUTI CE 50V 10U 20% RLT 5X11
C109,C110,C209,C210,C309,C310 157F-475M-K-IUTI CE 50V 4.7U 20% RLT 5X11
C810,C811 157I-227M-K-S9TI CE 63V 220U 20% RLT
C103,C104,C203,C204,C303,C304 157I-476M-K-OVTI CE 63V 47U 20% RLT
C101,C201,C301 157Q-106M-K-IUE CE 35V 10U 20% 5X11 RLT
DIODES
D103,D104,D203,D204,D303,D304 4804-0040-2 DIODE IN4004 AT
D101,D102,D201,D202,D301,D302 4804-1480-3 DIODE LL4148 SM
Z101,Z102,Z201,Z202,Z301,Z302 4837-27V0-2 DZ 1/2W 27V(26.2-27.6)AT
Z803 4837-5B11-2 DZ 1/2W 4.94~5.20V ROHM
WAFERS/SOCKETS
JP101A,JP102A 2101-1231-0 SPADE TERMINAL 6.3X0.8
P107B 2101-1801-0 SOCKET (PCB/PCB) 10P
P108A 2102-061R-004 WAFER 6 PIN P2.5
JACKS/SOCKETS
P101,P201,P301 2113-1160-0 WAFER 2P ST. P=2.5 NH
TRANSISTOR
Q101,Q201,Q301 4851-241A-5 TR RN1241-A
Q117,Q217,Q317 485A-1930-5 TR 2SA1930 HFE 100-320
Q109,Q110,Q209,Q210,Q309,Q310,Q828 485A-949O-5 TR 2SA949-O HFE 70-140
Q112,Q212,Q312 485C-2229-5 TR 2SC2229-0 HFE 70-140
Q116,Q216,Q316 485C-5171-5 TR 2SC5171 HFE 100-320
Q104,Q105,Q106,Q107,Q111,Q114, Q120, Q204,
Q205,Q206,Q207,Q211,Q214,Q220, Q304,Q305,
Q306,Q307,Q311,Q314,Q320, Q826,Q827
4860-0190-5 TR 2SC 1845 (F.E) RL
Q102,Q103,Q108,Q115,Q202,Q203,Q208, Q215,
Q302,Q303,Q308,Q315
4860-0660-5 TR 2SA1015 (G.R.) RL
Q113,Q213,Q313 4860-1220-5 TR 2SC3421 (0,Y) RL TSB
Q119,Q219,Q319 4860-3420-5 TR 2SA1987 TO-39 PNP
Q118,Q218,Q318 4860-3430-5 TR 2SC5359 TO-3P NPN
RESISTOR
R102,R112,R202,R212,R302,R312 4711-223A-2 RMF 1/8W 22K 1% AT
R125,R130,R225,R230,R325,R330 4715-822A-2 RMF 1/4W 8.2K 1% AT
R121,R122,R221,R222,R321,R322 4718-100J-2 RMF 1W 10R 5% AT
R137,R237,R337 4718-101J-C-X RMF 1W 100R 5% ATS METAL
R103,R104,R203,R204,R303,R304 4720-101A-J RMG 1/10W 100R 1% 0805
Reference No. Part No. Description
To Next Page
