Arcam AVR300 Service Manual

- 55 -
AVR300 SURROUND SOUND RECEIVER
R111,R114,R131,R132,R211,R214,R231, R232,
R311,R314,R331,R332
4720-102J-J RMG 1/10W 1K 5% 0805
R144,R145,R244,R245,R344,R345,R845 4720-103J-J RMG 1/10W 10K 5% 0805
R113,R213,R313 4720-123J-J RMG 1/10W 12K 5% 0805
R120,R220,R320 4720-180J-J RMG 1/10W 18R 5% 0805
R127,R128,R227,R228,R327,R328 4720-181J-J RMG 1/10W 180R 5% 0805
R107,R207,R307 4720-221J-J RMG 1/10W 220R 5% 0805
R118,R133,R134,R218,R233,R234,R318, R333,
R334
4720-222J-J RMG 1/10W 2.2K 5% 0805
R109,R116,R142,R143,R209,R216,R242, R243,
R309,R316,R342,R343,R842
4720-223J-J RMG 1/10W 22K 5% 0805
R115,R215,R315 4720-270J-J RMG 1/10W 27R 5% 0805
R139,R239,R339 4720-272J-J RMG 1/10W 2.7K 5% 0805
R141,R241,R341,R843,R844 4720-333J-J RMG 1/10W 33K 5% 0805
R140,R240,R340 4720-471J-J RMG 1/10W 470R 5% 0805
R119,R135,R136,R219,R235,R236,R319, R335,
R336
4720-561J-J RMG 1/10W 560R 5% 0805
R846 4720-562J-J RMG 1/10W 5.6K 5% 0805
R105,R106,R205,R206,R305,R306 4720-680A-J RMG 1/10W 68R 1% 0805
R101,R110,R201,R210,R301,R310 4720-681J-J RMG 1/10W 680R 5% 0805
R117,R123,R124,R217,R223,R224,R317, R323,
R324
4720-820J-J RMG 1/10W 82R 5% 0805
R108,R126,R129,R208,R226,R229,R308, R326,
R329
4720-822J-J RMG 1/10W 8.2K 5% 0805
R138,R238,R338 474B-R22K-5-02 RWR 5W 0.22R X2 10% RL
SEMI FIXED
VR101,VR201,VR301 4755-4715-3-00 SVR 470R 5X5.6 90DEG
HEATSINKS
Q116C,Q117C,Q216C,Q217C,Q316C,Q317C 5400-9130-0 HEAT SINK FOR 7805 2438-
WIRE
P102A 7012-6683-0 CONN WIRE 8P P=3.96
SCREW
Q116A,Q117A,Q216A,Q217A,Q316A,Q317A 2954-2606-0000 SCREWS BT 2.6X6
Q116B,Q117B,Q216B,Q217B,Q316B,Q317B 2954-3008-0000 TAPPING 3X8MM B-TITE
PC BOARD
1000 1725-695A-0001 PCB AMP1/AMP2/SW/RECT/
MISCELLANEOUS
SE802 8910-0489-0 THERMISTOR 100C
Reference No. Part No. Description
