AVR300 SURROUND SOUND RECEIVER
- 56 -
AUDIO ASSY
PC BOARD
PCB-AL050C-AUD PCB ASSY AUDIO AL050C
CAPACITORS
C3042,C3043,C3046,C3047,C3051,C3052,
C3053, C3054
150F-104K-J-BD CC 50V 0.1uF 10% 0805
C3001,C3002,C3003,C3004,C3005,C3006,
C3007, C3008,C3009,C3010,C3011, C3012,C30
13,C3014,C3015,C3016,C3101,C3102, C3103,C
3104,C3105,C3106,C3107,C3108, C3109,C3110
150F-221K-J-BD CC 50V 220pF 10% 0805 1.
C3135,C3136 157D-106M-K-IUI CE 16V 10UF 20% RLT 5X11
C3137,C3138 157D-227M-K-OVY CE 16V 220U 20% RLT
C3019,C3020,C3021,C3022,C3023,C3024,
C3039, C3040,C3041
157F-106M-K-IUI CE 50V 10UF 20% RLT 5X11
DIODES
D3010,D3011,D3012,D3013,D3014,D3015,
D3016, D3017
4804-1480-3 DIODE LL4148 SM
Z3001,Z3002 4837-4V76-2 DZ 1/2W 4.7V TEMIC AT
Z3003 4837-5B11-2 DZ 1/2W 4.94~5.20V ROHM
WAFERS/SOCKETS
P301A,P302A,P404B 2101-1521-0 SOCKET (PCB/PCB) 12P
JACKS/SOCKETS
VA301,VA302 2113-3058-0 JACK RCA 6P R/N GOLD W/O
VA303 2113-3059-0 JACK KCA 4P P/N GOLD W/O
TRANSISTOR
Q3001,Q3002,Q3003,Q3004 4851-241A-5 TR RN1241-A
RESISTOR
R3041,R3042 4711-331A-2 RMF 1/8W 330R 1% AT
R3063 4711-471A-2 RMF 1/8W 470R 1% AT
R3188,R3189,R3190,R3191 4720-000J-J RMG 1/10W 0R 5% 0805
R3029,R3030,R3035,R3036,R3079,R3080 4720-101J-J RMG 1/10W 100R 5% 0805
R3097,R3099 4720-103J-J RMG 1/10W 10K 5% 0805
R3003,R3004,R3007,R3008,R3011,R3012, R30
15,R3016,R3019,R3020,R3023, R3024,R3031,
R3032,R3037,R3038,R3103,R3104, R3107,
R3108,R3111,R3112,R3115,R3116, R3119,R3120
4720-104J-J RMG 1/10W 100K 5% 0805
R3081,R3082,R3183,R3184 4720-105J-J RMG 1/10W 1M 5% 0805
R3096,R3098 4720-203J-J RMG 1/10W 20K 5% 0805
R3001,R3002,R3005,R3006,R3009,R3010,R30
13, R3014,R3017,R3018,R3101,R3102,R3105,
R3106,R3109,R3110,R3113,R3114,R3117,R3118
4720-221J-J RMG 1/10W 220R 5% 0805
R3093,R3095 4720-243J-J RMG 1/10W 24K 5% 0805
Reference No. Part No. Description
To Next Page
