AVR300 SURROUND SOUND RECEIVER

R3021,R3022,R3025,R3026 4720-301J-J RMG 1/10W 300R 5% 0805

R3092,R3094 4720-473J-J RMG 1/10W 47K 5% 0805

U3006 3130-8160-0 IC TC9273N ANALOG SWITCH

U3001 3131-3570-0 IC TC9273N-004 ANALOG

U3005,U3007,U3008,U3010 3131-4850-0 IC NJM5532M JRC (SMD)

U3003,U3004 3132-0440-0 IC 74HC4053 SO-16

U3002 3132-1150-0 IC M62429FP ELECTRONIC

PC BOARD

3000 1725-693A-0001 PCB DSP/RS232/AUDIO

COM-VIDEO ASSY

PC BOARD

PCB-AL050C-COM PCB ASSY COM-VIDEO

CAPACITORS

C283,C285,C287,C288,C289,C290,C291, C292 150F-103K-J-BD CC 50V 0.01U 10% 0805

C216,C217,C218 150F-271J-J-BD CC 50V 270PF 5% 0805

C105,C105,C105 150F-331K-J-BD CC 50V 330pF 10% 0805 1.

C284,C286,C293,C294,C295,C296,C297, C298 157D-106M-K-IUI CE 16V 10UF 20% RLT 5X11

C299 157D-477M-K-OVI CE 16V 470UF 20% RLT

C222,C223,C224 15CH-220J-J-BD CTC 0/60 22PF 5% 0805

JACKS/SOCKETS

M201,M202 2113-3051-0 RCA 6P G/B/R GOLD SHIELD

COILS

L206,L207,L208 1803-0064-0 CHOKE COIL NCH-1471 SMD

TRANSISTOR

Q299 485C-114E-5 TR DTC114ES

RESISTOR

R279 4720-183J-J RMG 1/10W 18K 5% 0805

R280 4720-472J-J RMG 1/10W 4.7K 5% 0805

R263,R264,R265,R266,R267,R268,R269, R270,

R271,R274,R275,R276,R277,R281, R283,R284,

R285,R286,R287,R288,R289, R290,R291,R292,

R293,R295,R297,R299

4720-750J-J RMG 1/10W 75R 5% 0805

U201,U202,U204 3131-8950-0 IC LT1675CGN VIDEO SW

U203 3132-1160-0 IC LT1675CS8-1 VIDEO SW
