Arcam AVR300 Service Manual

AVR300 SURROUND SOUND RECEIVER
- 58 -
WIRE
P802 7012-6679-0 CONN WIRE 6P P=2.5 24AWG
P803 7012-6760-0 CONN WIRE 10P P=2.0
PC BOARD
2000 1725-695A-0001 PCB AMP1/AMP2/SW/RECT/
CONNECTOR ASSY
PC BOARD
PCB-AL050C-CONN PCB ASSY CONNECTOR
WAFERS/SOCKETS
J706C,J706D 2101-1520-0 WAFER (PCB/PCB) 12P P2.0
PC BOARD
7000 1725-695A-0001 PCB AMP1/AMP2/SW/RECT/
CONNECTOR2 ASSY
PC BOARD
PCB-AL050C-CONN2 PCB ASSY CONNECTOR2
WAFERS/SOCKETS
P107C,P107D 2101-1621-0 WAFER (PCB/PCB) 10P P2.0
PC BOARD
1020 1725-695A-0001 PCB AMP1/AMP2/SW/RECT/
DSP AL050C ASSY
PC BOARD
PCB-AL050C-DSP PCB ASSY DSP AL050C
CAPACITORS
C129 150F-102K-J-BD CC 50V 1000pF 10% 0805 1
C101,C105,C113,C124,C125,C130,C144,C145,
C146,C148,C149,C150,C151,C152,C153
150F-103K-J-BD CC 50V 0.01U 10% 0805
C175 150F-104K-2-FC CC 50V 0.1UF 10% AT
C104,C106,C107,C110,C111,C112,C116, C117,
C118,C119,C120,C121,C122,C123, C126,C127,
C128,C131,C135,C136,C137, C138,C139,C143,
C147,C158,C160,C161, C166,C167,C172,C173
150F-104K-J-BD CC 50V 0.1uF 10% 0805
C156 150F-122K-J-BD CC 50V 1200pF 10% 0805 1
C115 150F-222K-J-BD CC 50V 2200pF 10% 0805 1
C134 150F-223K-2-FD CC 50V 0.022uF 10% AT
Reference No. Part No. Description
