Arcam AVR300 Service Manual

- 59 -
AVR300 SURROUND SOUND RECEIVER
C174 150F-472K-J-BD CC 50V 4700pF 10% 0805 1
C155 150F-680K-J-BD CC 50V 68pF 10% 0805 1.2
C108,C109,C157,C162,C163,C164,C165, C168,
C169,C170,C171
154D-105M-3-CF CT 16V 1UF 20% SM
C154 154D-225M-3-CF CT 16V 2.2UF 20% SM
C102,C176 157B-108M-K-OVI CE 6.3V 1000UF 20%RLT 8X
C133,C140,C141,C142,C159 157D-106M-K-IUI CE 16V 10UF 20% RLT 5X11
C103 157D-476M-K-IUI CE 16V 47UF 20% RLT
C114,C132 157D-477M-K-OVI CE 16V 470UF 20% RLT
C178 157F-107M-K-OVI CE 50V 100U 20% RLT
DIODES
D101 4804-0020-2 DIO REC 1N4002GPE
D104,D105,D106,D107,D108,D109,D110, D111,
D112
4804-1480-3 DIODE LL4148 SM
WAFERS/SOCKETS
P110B,P111B 2101-1601-0 SOCKET (PCB/PCB) 16P
P122A 2102-041S-004 4P ST.WAFER
JACKS/SOCKETS
C0102 2113-1810-0 1P RCA JACK YL GOLD
CO101 2113-3044-0 4P RCA JACK BLACK
COILS
L101,L103,L105,L106,L107,L110 1801-100K-M COIL 10UH 10% BL7.0
L109 1802-0450-0 DIGITAL COIL
CRYSTAL
CR101 2300-3060-0 X’TAL 12.288MHZ +/-20PPM
TRANSISTOR
Q101,Q102 4860-8120-G TR 2SD1468S TPS ROHM
RESISTOR
R123 4715-103A-2 RMF 1/4W 10K 1% AT
R232,R233,R234,R235 4720-100J-J RMG 1/10W 10R 5% 0805
R100,R103,R111,R127,R128,R132,R133, R134,
R135,R136,R137,R138,R139,R140, R141,R142,
R143,R144,R145,R146,R147, R150,R153,R154,
R155,R156,R157,R158, R163,R164,R165,R166,
R174,R176,R177, R178,R179,R182,R186,R191,
R194,R195, R196,R208,R209,R210,R211,R219
4720-101J-J RMG 1/10W 100R 5% 0805
R106,R107,R108 4720-102J-J RMG 1/10W 1K 5% 0805
