Arcam AVR300 Service Manual

AVR300 SURROUND SOUND RECEIVER
- 60 -
R102,R114,R115,R116,R117,R118,R119,R120,
R131,R148,R149,R151,R152,R159, R160,R161,
R162,R167,R168,R169,R170, R171,R172,R173,
R175,R180,R181,R183, R187, R188,R189,R190,
R220,R221,R222, R223,R224
4720-103J-J RMG 1/10W 10K 5% 0805
R205 4720-122J-J RMG 1/10W 1.2K 5% 0805
R112,R129,R207 4720-202J-J RMG 1/10W 2K 5% 0805
R124 4720-222J-J RMG 1/10W 2.2K 5% 0805
R101,R104,R218 4720-302J-J RMG 1/10W 3K 5% 0805
R130,R225,R226,R227,R228,R229,R230, R231 4720-330J-J RMG 1/10W 33R 5% 0805
R212,R213,R214,R215,R216 4720-332J-J RMG 1/10W 3.3K 5% 0805
R109,R113,R122,R125,R126,R206 4720-471J-J RMG 1/10W 470R 5% 0805
R193,R201,R203,R288 4720-473J-J RMG 1/10W 47K 5% 0805
R185,R202,R204 4720-681J-J RMG 1/10W 680R 5% 0805
R105,R197,R198,R199,R200 4720-750J-J RMG 1/10W 75R 5% 0805
R110,R121,R184,R192,R290,R297 4720-911J-J RMG 1/10W 910R 5% 0805
IC
U104 3131-3940-0 IC 74HC245 BUS
U109 3131-7230-0 IC 74HC151 QUAD 4-PIN
U103 3131-8670-0 IC DIGITAL INPUT
U102,U105 3131-9100-0 IC 74HCU04 HEX INVERTERS
U108 3132-0230-0 IC SN74AC32 2-INPUT OR G
U101 3132-1050-0 IC CS494003 DSP CRYSTAL
U107 3132-1060-1 IC K4S161622H-UC60 SDRAM
U106 3132-1431-0 IC 29LV040 512KX8 256-B
WIRE
P103 7012-6747-0 CONN WIRE 2P P=2.5 24AWG
PC BOARD
1000 1725-693A-0001 PCB DSP/RS232/AUDIO
MISCELLANEOUS
L102,L112,L113 1808-0680-0 FERRITE BEAD INDUCTOR
M101 2704-0060-0 EMC FILTER
OP101,OP102,OP103 4811-F32R-3 LIGHT RX UNIT GPIF32R
OP104 4811-F32T-3 LIGHT TX UNIT GP1F32T
KEY ASSY
PC BOARD
PCB-AL050C-KEY PCB ASSY KEY AL050C
CAPACITORS
C1005,C1006,C1009 150F-103K-2-FC CC 50V 0.01uF 10% AT 3.5
Reference No. Part No. Description
