Arcam AVR300 Service Manual

- 61 -
AVR300 SURROUND SOUND RECEIVER
C1010 150F-104K-2-FC CC 50V 0.1UF 10% AT
C1014,C1015 150F-153K-2-FD CC 50V 0.015uF 10% AT
C1004 150F-470K-2-GD CC 50V 47P 10% AT
C1007,C1012,C1013,C1016 157B-477M-K-LUI CE 6.3V 470UF 20% RLT
C1011 157D-106M-K-GII CE 16V 10UF 20% RLT 4X5
C1003 157D-476M-K-IUI CE 16V 47UF 20% RLT
C1008 157F-107M-K-OVI CE 50V 100U 20% RLT
C1001,C1002 15CH-200J-2-FC CTC 0/60 20pF 5% AT
WAFERS/SOCKETS
P101A 2101-1441-0 FLEXIBLE CONN 15P P1.0 R
P1002A 2102-021R-004 WAFER 2P P2.5 RIGHT
P205B 2102-061R-004 WAFER 6 PIN P2.5
CRYSTAL
CR1001 2300-1920-0 X’TAL 11.0592 MHZ
TRANSISTOR
Q1005 485A-114E-K TR DTA114ESA RLT ROHM
Q1004 485C-114E-K TR DTC114ES RLT
Q1001,Q1002,Q1003 485C-123J-5 TR DTC123JSA ROHM
RESISTOR
R1001,R1002,R1003,R1004,R1005,R1006,
R1007, R1008,R1009,R1010,R1011,R1012,
R1014
4711-101A-2 RMF 1/8W 100R 1% AT
R1017 4711-102A-2 RMF 1/8W 1K 1% AT
R1018,R1019,R1030 4711-103A-2 RMF 1/8W 10K 1% AT
R1020 4711-220A-2 RMF 1/8W 22R 1% AT
R1016 4711-332A-2 RMF 1/8W 3.3K 1% AT
R1015 4711-471A-2 RMF 1/8W 470R 1% AT
R1022,R1023,R1024,R1025,R1026,R1027,
R1028, R1029
4711-472A-2 RMF 1/8W 4.7K 1% AT
IC
U1002 3132-1030-0 IC AT89S52 8BIT MICROCON
U1001 3132-1090-0 IC PT6302 VFD DRIVER
SWITCH
SW1001,SW1002,SW1003,SW1004, SW1005,
SW1006,SW1007,SW1008, SW1009, SW1010,
SW1011,SW1012,SW1013,SW1014,SW1015,
SW1016,SW1017, SW1018,SW1019,SW1020,
SW1021,SW1022,SW1023,SW1024,SW1025,
SW1026
5200-3628-0-00 TACT SW SKHHBY 7MM HIGH
Reference No. Part No. Description
