Arcam AVR300 Service Manual

- 63 -
AVR300 SURROUND SOUND RECEIVER
C112 157D-228M-5-X=I CE 16V 2200UF 20% RL
C111 157D-335M-K-IUI CE 16V 3.3UF 20% 5X11
C103,C104,C118 157D-476M-K-IUI CE 16V 47UF 20% RLT
C135,C143,C145 157D-477M-K-OVI CE 16V 470UF 20% RLT
C102 157E-108M-K-S9I CE 25V 1000UF 20% RLT
C110,C133 157E-108M-K-X9TI CE 25V 1000U 20% RLT
C134 157E-227M-K-OVI CE 25V 220UF 20% RLT
C142 157E-228M-5-X&E CE 25V 2200UF 20% RL
C121 157E-338M-5-5&TI CE 25V 3300U 20% RL
C101 157E-478M-5-5$TI CE 25V 4700U 20% RL
C146,C147 157F-106M-K-IUI CE 50V 10UF 20% RLT 5X11
C106 157F-107M-K-OVI CE 50V 100U 20% RLT
C107 157F-476M-K-LUI CE 50V 47UF 20% RLT
C116,C117,C119,C120 15CH-200J-2-FC CTC 0/60 20pF 5% AT
DIODES
D101,D102,D103,D104,D105,D106,D107,
D108, D109,D110,D111,D112,D113,D116, D119,
D120, D121, D122,4,D115,D116,D123,D124,
D125,D126, D127,D128,D141,D142,D143, D144,
D145,D146,D148,D149,D150,D151, D152
4804-0040-2 DIODE IN4004 AT
D117,D118,D129,D130,D131,D132,D133, D134,
D135,D136,D137,D138,D139,D140, D147
4804-1480-2 DIODE 1N4148 AT
Z105 4837-13C1-2 DZ 1/2W 13VC MTZJ13C
Z101 4837-27V0-2 DZ 1/2W 27V(26.2-27.6)AT
Z102,Z103,Z104 4837-5B11-2 DZ 1/2W 4.94~5.20V ROHM
WAFERS/SOCKETS
U101,U102 2101-0841-0 PLCC SOCKET 44 PIN (4X11
DP101 2101-1231-0 SPADE TERMINAL 6.3X0.8
P106A,P301A,P302A 2101-1520-0 WAFER (PCB/PCB) 12P P2.0
P101B 2101-1536-0 FFC CONNECTOR 15P P1.0
P802A 2101-1621-0 WAFER (PCB/PCB) 10P P2.0
P105A,P110B,P111B,P402A,P403A,P406A,
P803A
2101-1641-0 WAFER (PCB/PCB) 16P P2.0
P107,P108 2102-021S-004 2P ST.WAFER
P300 2102-031S-004 3 PIN ST. WAFER
P803B 2102-081S-004 WAFER 8P P2.5 ST.
P104B 2102-101S-004 WAFER 10P P2.5 ST.
P120 2102-121S-004 12P ST.WAFER
CRYSTAL
CR101,CR102 2300-1920-0 X’TAL 11.0592 MHZ
TRANSISTOR
Q117,Q118 4851-241A-5 TR RN1241-A
Reference No. Part No. Description
