Arcam AVR300 Service Manual

AVR300 SURROUND SOUND RECEIVER
- 84 -
0204 4154-7501-0 PCB SUPORT A=16MM
0205,0240,0241 *CE BLACK / CE SILVER 2601-3008-0801 FIBRE WASHER M3X0.8X8MM
0208 4135-4331-0 METAL BRACKET FOR
0209,0215 6360-9690-0 WS CLAMP WS-IU UL94V-0
0210 4157-0701-0 RUBBER CUSHION 30*30*22
0211 4155-0041-0 PCB-SUPPORT A=9.4MM
0212 2606-3005-0642 I/T WASHER M3X0.5X6.4 WZ
0214 5200-3627-0 SL14-22AH (1A) SW 2P2T
0239 3716-9911-0 LED -LENS PAINTED BLACK
0246 4155-0131-0 PC SHEET 42*12*0.5MM
0247 4155-0121-0 PC HEET 56*28*0.5MM
0248 4155-0111-0 PC SHEET 23.5*20*0.3MM
0249 4157-0681-0 RUBBER CUSHION 25X15X4MM
0250 3000-9519-0 LABEL REO GROUND SYMBOL
0251 1808-0800-0 FERRITE EMI DISK
0252 4131-7701-0 ANTENNA WASHER
0254 4135-3291-0 CLIP 27255004-1 CP701
GND 7012-6772-0 CONN WIRE UL1015 18AWG
L101 1808-0780-0 CLAMP CORE FOR EMI GMAA
P806 7012-6687-0 FFC 15P P=1.0 AWM E81015
P873,P874 7012-6751-0 CONN WIRE 2P L=100MM
Reference No. Part No. Description
