Arcam AVR850 User Manual

E-19
English
Mutes all analogue audio outputs in the
currently selected zone.
Switches the main power to the
Receiver on and o.
Once the unit is switched o, it
should be le for at least ten seconds
before switching on again.
Auxiliary line level input.
is socket accepts headphones with
an impedance rating between 32Ω and
600Ω, tted with a 3.5mm stereo jack
plug.
is switches the display brightness
between o/dim/bright.
Selects between Zone1 and
Zone2 control.
is indicates the status of the receiver and is
green when the Receiver is powered on. Red
indicates the unit is in Standby mode.
Used to enter selections made in the
Setup menu.
Selects the information displayed on the
lower le portion of the front panel.
Selects between Stereo
and the available surround
modes for the current
source.
Stereo Direct on/o. Provides a direct analogue path from
the analogue inputs to the le and right front outputs.
Switches o any surround processing modes and shuts
down the DSP circuits for best stereo sound quality.
AVR850
Remote control receiver. is is positioned behind
the display window, above the MENU button on the
front panel. Ensure the receiver is in a clear line of
sight from the remote control for operation. If this is
not possible, use a separate sensor connected to the
Z1 IR input on the rear panel.
front panel
operation
Adjusts the analogue output
volume in the selected zone
(line out, speakers and
headphones).
ese buttons select the source
connected to the corresponding
input (or internal input)
Unused sources can be prevented
from being selected in the setup
menu by blanking the name in
MENU > Input Cong.
Selects the Setup menus on the
on-screen display (OSD).
Info
Mode
Direct
Display
OK
Zone
Power/Standby LED
Phones
Aux
Power
Input
Menu
Volume
Mute

Arcam AVR850 Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	110 dB
Power output per channel (20-20KHz@8 Ohm)	- W
Power consumption (standby)	0.5 W
Power consumption (typical)	1500 W
Card reader integrated	No
Package weight	20000 g
HDMI in	7
Ethernet LAN (RJ-45) ports	1
Number of HDMI outputs	3
12V trigger	Yes
12V trigger ports quantity	2
Speakers connectivity type	-
Supported radio bands	DAB, DAB+, FM
Internet radio services supported	Spotify
Audio decoders	DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD Master Audio
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	425 mm
Width	433 mm
Height	171 mm
Weight	16700 g
