Arcam AVR850 User Manual

E-24
SAT Device Mode
e SAT Device Mode button selects SAT as the source.
If congured to work with your satellite receiver, the
remote can subsequently control the device.
2
Toggles power between standby and on.
0...9
Functions as original remote number key –
usually for channel selection.
DISP
Display INFO or OSD (On Screen Display)
function, if available.
9
Channel down.
9
Channel up.
INFO
Displays programme information.
POP UP
Guide (or Setup on some set top boxes).
Navigate setup and programme selection
menus.
OK conrms a selection (equivalent to
‘Enter’ or ‘Select’ on some remotes).
Returns navigation to the top level of the
menu (‘Home’).
RTN
Back.
AMP
Resets remote to AMP mode.
RED
RED button for Satellite.
GREEN
GREEN button for Satellite.
YELLOW
YELLOW button for Satellite.
BLUE
BLUE button for Satellite.
2
Toggles power between standby and on.
0...9
Functions as original remote number key –
usually for channel selection.
DISP
Display INFO or OSD (On Screen Display)
function, if available.
MODE
Selects the Library or Media function.
7
Rewind.
8
Fast Forward.
9
Channel down.
9
Channel up.
Stop playback.
4;
Pause and playback of the current track.
Record.
INFO
Opens the EPG (Electronic Program Guide)
on some satellite and cable set top boxes.
POP UP
Turns on the Menu function if the set top
box uses this feature.
Navigate setup and programme selection
menus.
OK conrms a selection (equivalent to
‘Enter’ or ‘Select’ on some remotes).
Returns navigation to the top level of the
menu (‘Home’).
AUDIO
Selects the Help function.
AMP
Resets remote to AMP mode.
RED
RED button for set top box.
GREEN
GREEN button for set top box.
YELLOW
YELLOW button for set top box.
BLUE
BLUE button for set top box.
2
Toggles power between standby and on.
0...9
Functions as original remote number key –
usually for channel selection.
INFO
Display INFO or OSD (On Screen Display)
function, if available.
MODE
Selects the Library or Media function.
7
Rewind.
8
Fast Forward.
9
Channel down.
:
Channel up.
Stop playback.
4;
Pause and playback of the current track.
Record.
MENU
Opens the EPG (Electronic Program Guide)
on some satellite and cable set top boxes.
POP UP
Turns on the Menu function if the PVR uses
this feature.
Navigate setup and programme selection
menus.
OK conrms a selection (equivalent to
‘Enter’ or ‘Select’ on some remotes).
Returns navigation to the top level of the
menu (‘Home’).
AUDIO
Selects the Help function.
AMP
Resets remote to AMP mode.
RED
RED button for PVR.
GREEN
GREEN button for PVR.
YELLOW
YELLOW button for PVR.
BLUE
BLUE button for PVR.
STB Device Mode
e STB Device Mode button selects STB as the source.
If congured to work with your set top box decoder or
similar device, the remote can subsequently control the
device.
PVR Device Mode
e PVR Device Mode button selects PVR as the source.
If congured to work with your personal (hard disc)
video recorder or similar device, the remote can
subsequently control the device.

Arcam AVR850 Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	110 dB
Power output per channel (20-20KHz@8 Ohm)	- W
Power consumption (standby)	0.5 W
Power consumption (typical)	1500 W
Card reader integrated	No
Package weight	20000 g
HDMI in	7
Ethernet LAN (RJ-45) ports	1
Number of HDMI outputs	3
12V trigger	Yes
12V trigger ports quantity	2
Speakers connectivity type	-
Supported radio bands	DAB, DAB+, FM
Internet radio services supported	Spotify
Audio decoders	DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD Master Audio
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	425 mm
Width	433 mm
Height	171 mm
Weight	16700 g
