Arcom RC210 User Manual

Programming Commands Quick Reference
Code What It Programs What It Means
*1000 Program Transmitter Hang Timer Programs the xmtr Hang Timer for the currently unlocked Port
*1001 Program Time Out Time Programs the Timeout Timer for the currently unlocked Port
*1002 Program Initial ID Period Programs the Initial ID Timer for the currently unlocked Port
*1003 Program Pending ID Period Programs the Pending ID Timer for the currently unlocked Port
*1004 Program Fan Time Programs the length of time the Fan will remain on after xmtr drop
*1005 Program Port Activity Timer Programs the Link Inactivity Timer for the currently unlocked Port
*1006 Program DTMF Mute Timer Programs the DTMF Mute Timer for the currently unlocked Port
*1007 Program CTCSS Encode Timer Programs the CTCSS Encode Timer for the currently unlocked Port
*1008 Program Kerchunk Timer Timeout Programs how long until the Kerchunk Timer times out
*1009 Program Timeout Reset Timer Programs how long after signal disappears to Timeout Timer Reset
*1013 Program Aux Audio 1 Time Out Timer Programs how long Aux Audio 1 remains ON
*1014 Program Aux Audio 2 Time Out Timer Programs how long Aux Audio 2 remains ON
*1015 Program Aux Audio 3 Time Out Timer Programs how long Aux Audio 3 remains ON
*1017xy Program General Timer Period Programs the General Timers timeout period
*1018 Program the Kerchunk Filter Delay Period Programs the Kerchunk filtering time on the currently unlocked Port
*1019 Set Pending ID Speak Timer Controls how Pending ID Voice/CW IDs are processed
*1020 Set Announce Timer Sets how long Tail Message will play after repeater activity stops
*1021 Set CTCSS Encode Control Polarity Sets whether the Encode Control Line is active high or active low
*1022 Set Speech/CW Delay Sets wait time before speech or CW if xmtr not currently active
*1024 Set AutoPatch Timeout Sets the autopatch timeout period.
*1025x Set Autopatch Number of Rings Sets how many rings before the Autopatch answers
*2050xx Program Command Macro Recall Code Programs the code used to recall remapped Command Macros
*2051x Program Linked Ports Timeout Programs whether a linked Port will timeout from another Port
*2060 Program Remote Base Prefix Programs the Prefix prepended to default Remote Base commands
*2061 Program Autopatch Prefix Code Programs the Prefix prepended to Autopatch commands
*2062 Program Autopatch Blacklist Programs numbers to disallow from manually dialing
*2063 Program Autopatch Security Code Programs the code that must be entered when Autopatch answers
*2064 Program A/D Channel Programs the channel and meter face
*2065 Program Vref Programs the voltage reference used for A/D measurements
*2066 Program Meter Alarm Programs the high and low trip points for the Meter Alarms
*2083 Set Radio Type Select which type of radio is used as a Remote Base
*2084 Set Yaesu Type If Yaesu is selected, select which type format to use
*2086 Store Remote Base Memory Store Remote Base frequency, CTCSS and offset in controller's
non-volatile memory
*2087 Store Kenwood V7/G707 Memory Store memory in radio itself
*2088x Select CTCSS -COS or Courtesy Tone Select CTCSS encode timer after COS or after Courtesy Tone
*2089x CTCSS During ID 1 = CTCSS During ID. 0 = no CTCSS During ID
*2090x TT Mute on 1st or 2nd Digit 1 = 1st Digit, 2 = 2nd Digit
*2091x Allow/Don't allow Terminator Speech Select if speech is generated even with Terminator.1 = yes, 0 = no
*2092xy General Timer Macro Select Selects which Command Macro a General Timer uses
*2093x User DTMF Pad Test Prefix Program the prefix used for the DTMF Pad Test (1 - 5 digits)
*2101 Program Falling Alarm Macro Selects which Macro to run on a High-to-low transition
*2102 Program Rising Alarm Macro Selects which Macro to run on a Low-to-high transition
*2103 Program Message Macros Program the messages using in Message Macros
*2104 DTMF Regen Prefix Programs the prefix to use to send regenerated DTMF to a Port
*2105 Program DTMF Memory Programs the DTMF sequence to be sent
*2106 Program Send DTMF Duration Programs the duration of transmitted DTMF digits
*2107 Program DTMF Pause Time Programs the period between transmitted DTMF digits
*2108x Program Pre Access Code Programs whether all codes while unlocked use a prefix
*2109x Program Pre Command Code Programs whether there is access to default command when locked
*2110x Program Tail Message Programs a Tail Message for the currently unlocked Port
*2111x Select Tail Message Selects Tail Message 1, 2 or 3 for the currently unlocked Port
*2112x Select Tail Counter Sets the Tail Message Counter (0 to 254) 0 turns the counter OFF
*2113yxx Program Receiver Macro Function Program Receiver Active/Inactive Macro Function
*2114x Port Inactivity Timeout Macro Select Select which Macro to run when a linked Port Timeout occurs
*2115x Autopatch Autodial Number Store Stores Autopatch Autodial numbers for automatic dialing
*2116x Autopatch Port Restrictions Programs which port(s) the Autopatch may be used from
*2117x User DTMF Out Port Programs which port(s) User DTMF should be sent to.
*2118x User DTMF Message Program Programs which Message Macro is spoken before DTMF sent
*2119x Controls why fan starts 0= start for all xmtr activity 1=start only for valid signal/AP/Aux Aud
*2121x ID Timers start on COS or PTT ID Timers start on COS or PTT on the currently Unlocked Port
*2122x Timeout Timer Reset Select Selects the point where the Timeout Timer is reset
*2123x Select Wind Direction Read back Selects either degrees or compass heading for Wind Direction
