DIVISION II - OPERATION/
MAINTENANCE
ATV Specifications
Specifications subject to change without notice.
ENGINE
450
Type Four-Cycle/Liquid Cooled
Bore x Stroke 89 mm x 71.12 mm (3.5 x 2.8 in.)
Displacement 442.45 cc (27 cu in.)
Spark Plug Type NGK CR7E
Spark Plug Gap 0.7-0.8 mm (0.028-0.031 in.)
Brake Type Dual lever, independent front & rear
hydraulic brakes w/foot brake
CHASSIS
Length (Overall) 186.2 cm (73.3 in.)
Height (Overall) 118.9 cm (46.8 in.)
Width (Overall) 120.7 cm (47.5 in.)
Suspension Travel (Front/Rear) 17.7 cm (7.0 in.)
Tire Size (Front) 23 x 8-12
Tire Size (Rear) 23 x 10-12
Tire Inflation Pressure 40 kPa (5.7 psi)
MISCELLANY
Dry Weight (Approx) 272.2 kg (600 lb)
Gas Tank Capacity 16.3 L (4.3 U.S. gal.)
Differential Capacity 275 ml (9.3 fl oz)
Coolant Capacity 1.8 L (1.9 U.S. qt)
Rear Drive Capacity 250 ml (8.5 fl oz)
Engine Oil Capacity (Approx) 2.8 L (3.0 U.S. qt)
Gasoline (Recommended) 87 Octane Regular Unleaded
Engine Oil (Recommended) Arctic Cat ACX All Weather (Synthetic)
Differential/Rear Drive Lubricant SAE Approved 80W-90 Hypoid
Taillight/Brakelight 12V/5W/21W
Headlight 12V/35W (4)
Running Light 5W
Starting System Electric
