3. Mode Button - Shifts the gauge
through three set-up modes: speedom-
eter/tachometer, distance, and time.
NOTE: The Mode Button must be
pressed and released to shift modes.
Approximately two seconds after the
Mode Button is released, the digital
gauge will return to full display.
4. Set/Reset Button - In conjunction
with the Mode Button, sets and resets
various displays on the digital gauge.
Also used to shift from speedometer
function to tachometer function on
the speedometer/tachometer gauge.
5. Fuel Level Indicator - Indicates
approximate amount of fuel in the
fuel tank.
NOTE: When the bottom seg-
ment flashes, approximately 3.5 L
(0.92 U.S. gal.) of fuel remains in the
tank.
6. Low Oil Pressure - Will be displayed
during self-test at start-up. It will not
be displayed during normal operation
unless the oil pressure falls below
approximately 1.05 kg/cm
2
(15 psi).
The digital gauge will go blank and
the oil pressure icon will flash for 30
seconds; then the digital gauge will
return to normal with the oil pressure
icon continuing to flash.
7. Odometer/Trip Meter - Odometer reg-
isters the total distance the vehicle has
traveled. The trip meter is resetable
and can be used to measure trip or trip
legs. The odometer cannot be reset.
NOTE: To shift between the
odometer (ODO) or trip meter
(TRIP), press the Mode Button (3) to
select the distance mode; then
press the Set/Reset Button (4) to
select the desired display. Hold the
Set/Reset Button down to reset the
trip meter.
8. Gear Position Indicator - Indicates
which gear is selected.
• R (reverse)/N (neutral)/H (high range)/
L (low range).
NOTE: An E will be displayed if
there is an error caused by a no-
shift position signal.
9. High Beam Indicator - The High
Beam icon will appear only when the
headlights are on high beam.
10. 4WD Lock Indicator - Displays
LOCK when the front differential
lock has been engaged.
11. Drive Select Indicator - Displays
4WD when selected by the drive
select switch or when the 4WD lock
is engaged. The display is blank when
in 2WD.
12. Speedometer - Indicates the approxi-
mate vehicle speed in miles per hour
(MPH) or kilometers per hour (km/h).
NOTE: To change mph/km/h dis-
play, press and release Mode But-
ton (3) until the icon (MPH/km/h)
appears; then press the Set Button
(4) to change the display.
Fuel/Vent Hoses
Replace the fuel hoses every two years.
Damage from aging may not always be
visible. Do not bend or obstruct the rout-
ing of the fuel tank vent hose.
Level Stick (Engine Oil)
There is a level stick for checking the
engine oil level. To check the oil level,
use the following procedure.
CAUTION
Arctic Cat does not recommend
using a pressure washer to clean the
radiator core. The pressure may bend
or flatten the fins causing restricted
air flow, and electrical components
on the radiator could be damaged.
Use only a garden hose with spray
nozzle at normal tap pressure.
CAUTION
Continued operation with low oil
pressure will result in serious engine
damage. Shut the ATV off and deter-
mine the cause of low oil pressure.
