ATV Specifications
Specifications subject to change without notice.
ENGINE 450/550/700
Type Four-Cycle/Liquid Cooled OHC
Bore x Stroke 89 mm x 71.12 mm (3.5 x 2.8 in.) - 450
92 mm x 82 mm (3.62 x 3.22 in.) - 550
102 mm x 85 mm (4.01 x 3.35 in.) - 700
Displacement 442 cc (27 cu in.) - 450
545 cc (33.6 cu in.) - 550
695 cc (42.4 cu in.) - 700
Spark Plug Type NGK CR7E - 450
NGK CPR8E - 550/700
Spark Plug Gap 0.5-0.6 mm (0.019-0.024 in.) - 550/700
0.7-0.8 mm (0.028-0.031 in.) - 450
Brake Type Hydraulic w/Brake Lever Lock and Rear Foot Brake
CHASSIS
Length (Overall) 215 cm (84.75 in.)
249 cm (98.00 in.) - TBX
219.71 cm (86.5 in.) - Mud Pro
Height (Overall) 122.0 cm (48.0 in.) - 700
125 cm (49.3 in.) - 450/550/TBX
131.45 cm (51.75 in.) - Mud Pro
Width (Overall) 120.7 cm (47.5 in.)
Suspension Travel (Front/Rear) 25.4 cm (10 in.)
Tire Size (Front) 25 x 8-12
28 x 9-14 - Mud Pro
Tire Size (Rear) 25 x 10-12
28 x 11-14 - Mud Pro
Tire Inflation Pressure 0.35 kg/cm² (5.0 psi)
MISCELLANY
Dry Weight (Approx) 314 kg (692 lb) - 450
316 kg (697 lb) - 550/700
361 kg (796 lb) - TBX
360 kg (793 lb) - Mud Pro
Gas Tank Capacity 21.6 L (5.7 U.S. gal.)
22.0 L (5.8 U.S. gal.) - TBX
Coolant Capacity N/A - 450
2.9 L (3.0 U.S. qt) - 550/700
Differential Capacity 275 ml (9.3 fl oz)
Rear Drive Capacity 250 ml (8.5 fl oz)
Engine Oil Capacity (Approx) 2.8 L (3.0 U.S. qt) - 450
1.9 L (2.0 U.S. qt) - 550/700
Gasoline (Recommended) 87 Octane Regular Unleaded
Engine Oil (Recommended) Arctic Cat ACX All Weather (Synthetic)
Front Differential/Rear Drive Lubricant SAE Approved 80W-90 Hypoid
Taillight/Brakelight 12V/8W/27W
Headlight 12V/27W (4)
Starting System Electric
