Division II - Operation/
Maintenance
ATV Specifications
Specifications subject to change without notice.
ENGINE AND DRIVE
Type Four-Cycle/OHC/Air Cooled
Bore x Stroke 62 x 49.5 mm (2.44 x 1.95 in.)
Displacement 149 cc (9.1 cu in.)
Spark Plug Type DR8EA
Spark Plug Gap 0.6 mm (0.024 in.)
Brake Type Front Double Drum/Rear Hydraulic
Disc w/Brake Lever Lock
CHASSIS
Length (Overall) 177.8 cm (69.9 in.)
Height (Overall) 103.8 cm (40.9 in.)
Width (Overall) 95.0 cm (37.4 in.)
Tire Size (Front) 21 x 7-10
Tire Size (Rear) 22 x 10-10
Tire Inflation Pressure (Front)
(Rear)
27.6 kPa (4.0 psi)
24.1 kPa (3.5 psi)
MISCELLANY
Dry Weight (Approx) 157.9 kg (349 lb)
Gas Tank Capacity (Rated) 8.7 L (2.3 U.S. gal.)
Transmission Lubricant (Recommended) SAE 80W-90 Hypoid
Transmission Lubricant Capacity 300 ml (10 fl oz)
Engine Oil Capacity (Approx) 1.0 L (1.06 U.S. qt)
Gasoline (Recommended) 87 Octane Regular Unleaded
Engine Oil (Recommended) Arctic Cat ACX All Weather
(Synthetic)
Headlights 12V/35W/35W (2)
Parking Lights 12V/5W (2)
Brakelights/Taillights 12V/21W/5W (2)
Starting System Electric w/Kick Start (Emer-
gency)
