Arduino Portenta Mid Carrier User Manual

Arduino® Portenta Mid Carrier
15 / 30 Arduino® Portenta Mid Carrier Modified: 09/04/2024
4.3.5 MIPI Connector (J10)
The MIPI connector J10 of the Portenta Mid Carrier can be used to connect compatible MIPI cameras to the carrier.
Notice that MIPI cameras are only compatible with the Portenta X8 board.
Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
1 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
2 N/A CAM_D0_D0_N J2-16
3 N/A CAM_D1_D0_P J2-14
4 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
5 N/A CAM_D2_D1_N J2-12
6 N/A CAM_D3_D1_P J2-10
7 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
8 N/A CAM_CK_CK_N J2-20
9 N/A CAM_VS_CK_P J2-18
10 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
11 N/A GPIO_5 J2-56
12 N/A NC NC
13 N/A I2C1_SCL J1-45 I2C 1 SCL
14 N/A I2C1_SDA J1-43 I2C 1 SDA
15 N/A
+3V3
Portenta
VCC J2-23, J2-34, J2-43, J2-69
4.3.6 DVP Interface Connector (J11)
The DVP interface connector J11 of the Portenta Mid Carrier can be used to connect compatible Arducam® DVP
camera modules to the carrier.
Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
1 VCC
+3V3
Portenta
VCC J2-23, J2-34, J2-43, J2-69
2 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
3 SCL0 I2C0_SCL J1-46 I2C 0 SCL
4 SDA0 I2C0_SDA J1-44 I2C 0 SDA
5 VSYNC CAM_VS_CK_P J2-18
6 HREF CAM_HS J2-22
7 PCLK CAM_CK_CK_N J2-20
8 XCLK PWM_0 J2-59
9 DOUT7 CAM_D7_D3_P J2-2
10 DOUT6 CAM_D6_D3_N J2-4
11 DOUT5 CAM_D5_D2_P J2-6
12 DOUT4 CAM_D4_D2_N J2-8
