Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
12 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
13 DSI D2N DSI_D2_N J1-8 DSI D2 N
14 DSI D2P DSI_D2_P J1-6 DSI D2 P
15 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
16 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
17 DSI D3N DSI_D3_N J1-4 DSI D3 N
18 DSI D3P DSI_D3_P J1-2 DSI D3 P
19 NC NC NC
20 NC NC NC
21 VIN +5V VIN J1-21, J1-24, J1-32, J1-41, J1-48
22 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
23 VCC
+3V3
Portenta
VCC J2-23, J2-34, J2-43, J2-69
24 VIN +5V VIN J1-21, J1-24, J1-32, J1-41, J1-48
4.3.11 Mini PCIe Connector (J8)
The Mini PCIe connector J8 of the Portenta Mid Carrier can connect compatible Mini PCie cards, for example, the
Arduino® Pro 4G Module EMEA (SKU: TPX00201), to the carrier and the connected Portenta family board.
Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
1 N/A
2 N/A +3V3 PCIE
3 N/A
4 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
5 N/A
6 N/A
7 N/A GPIO_1 J2-48
8 N/A USIM PWR
9 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
10 N/A USIM DATA
11 N/A PCIE_CK_N J2-19 PCIE CK N
12 N/A USIM CLK
13 N/A PCIE_CK_P J2-17 PCIE CK P
14 N/A USIM RST
15 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
16 N/A
17 N/A
