Arduino Portenta Mid Carrier User Manual

Arduino® Portenta Mid Carrier
16 / 30 Arduino® Portenta Mid Carrier Modified: 09/04/2024
Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
13 DOUT3 CAM_D3_D1_P J2-10
14 DOUT2 CAM_D2_D1_N J2-12
15 DOUT1 CAM_D1_D0_P J2-14
16 DOUT0 CAM_D0_D0_N J2-16
17 PWRENABLE GPIO_3 J2-52
18 PWDN GPIO_4 J2-54
19 PWRENABLE GPIO_3 J2-52
20 PWDN GPIO_4 J2-54
4.3.7 USB-A 2.0 Female Connector (J13)
The USB-A 2.0 female connector J13 of the Portenta Mid Carrier can be used for data logging operations and to
manage external peripherals with the connected Portenta family board to the carrier.
Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
1 N/A +5V VIN J1-21, J1-24, J1-32, J1-41, J1-48
2 N/A USB0_D_N J1-28 USB D-
3 N/A USB0_D_P J1-26 USB D+
4 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
4.3.8 microSD Card Slot (J12)
The microSD card slot J12 of the Portenta Mid Carrier can be used for bootloading and data logging operations.
Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
1 N/A SDC_D2 J1-63
2 N/A SDC_D3 J1-65
3 N/A SDC_CMD J1-57
4 N/A VDDSDCARD VSD J1-72
5 N/A SDC_CLK J1-55
6 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
7 N/A SDC_D0 J1-59
8 N/A SDC_D1 J1-61
CD1 N/A SDC_CD J1-67
CD2 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
