Arduino Portenta Mid Carrier User Manual

Arduino® Portenta Mid Carrier
17 / 30 Arduino® Portenta Mid Carrier Modified: 09/04/2024
4.3.9 RJ45 Ethernet Connector (J18)
The RJ45 Ethernet connector J18 of the Portenta Mid Carrier can be used for Internet connectivity and networking
via Ethernet.
Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
1 N/A VCC VCC (through SW3) J2-23, J2-34, J2-43, J2-69
2 N/A ETH_C_N J1-11
3 N/A ETH_C_P J1-9
4 N/A ETH_B_P J1-5
5 N/A ETH_B_N J1-7
6 N/A VCC VCC (through SW3) J2-23, J2-34, J2-43, J2-69
7 N/A VCC VCC (through SW3) J2-23, J2-34, J2-43, J2-69
8 N/A ETH_D_P J1-13
9 N/A ETH_D_N J1-15
10 N/A ETH_A_N J1-3
11 N/A ETH_A_P J1-1
12 N/A VCC VCC (through SW3) J2-23, J2-34, J2-43, J2-69
13 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
14 N/A ETH_LED2 J1-19 (through resistor)
15 N/A ETH_LED1 J1-17
16 N/A VCC VCC (through resistor) J2-23, J2-34, J2-43, J2-69
17 N/A NC NC
4.3.10 GIGA Display Shield Connector (J19)
The GIGA Display Shield connector J19 of the Portenta Mid Carrier can connect the GIGA Display Shield (SKU:
ASX00039) to the carrier and the connected Portenta family board.
Pin Number Silkscreen Power Net Portenta HD Standard Pin High-Density Pin Interface
1 DSI D1N DSI_D1_N J1-12 DSI D1 N
2 DSI D1P DSI_D1_P J1-10 DSI D1 P
3 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
4 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
5 DSI CKN DSI_CK_N J1-20 DSI CK N
6 DSI CKP DSI_CK_P J1-18 DSI CK P
7 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
8 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
9 DSI D0N DSI_D0_N J1-16 DSI D0 N
10 DSI D0P DSI_D0_P J1-14 DSI D0 P
11 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54
J2-24, J2-33, J2-44, J2-57, J2-70
