User Manual – Arenal PCS – QA03-SDA Page 10/74
2.Technicalspecifications
2.1 Environmental characteristics
Ingress Protection QA03: IP65 (Limited due to touch screen display on front side. We recommend
mounting the analyzer inside a protective FRM or GRP cabinet)
QT0161: IP66. We recommend mounting the electronics NOT in direct sunlight.
QP015: IP68
Temperature Operating: 0‐50 degC
Storage: ‐10ºC to +60ºC
RH Relative humidity 10‐90% (non condensing)
Leakage protection Double NBR o‐ring and dual packing in case of QB021‐WDL
2.2 Operation characteristics
Interfaces Ethernet LAN RJ‐45 10Base‐T/100Base‐TX
USB2.0 type A
Modbus RTU over 2 wire RS485
Power 90‐263 Vac. 50‐60Hz Standard (select VAC model)
18‐32 Vdc Standard (select 24V model)
Consumption: 15W
Display 5,7” Color LCD soft touch screen display
256 colors, 320x240 pixels, 6MB FEPROM
Response time Sensor pulse repeat frequency: 0,001 seconds, averaged over 1 second. Updated
every second in the analyzer. Moving average can be set between 1‐60 seconds.
Measurement absolute
error
In tap water within calibrated temperature range: 3 g/l.
In slurry: average error is 9‐15 g/l, due to changing morphology of particles,
inhomogeneous state of slurry and temperature sensitivity of dissolved solids.
Measurement relative
error
15 g/l in the range 1000‐2500 g/l is 1%
Ageing About 1% per year. Perform a water calibration each 3 months.
Weight 2,5 kg
Dimensions Outside dimensions: 330x200 mm. Depth: 120 mm
Housing Aluminum die case with dry coating
Mounting Mounting holes available: just remove the aluminum panels, no need for opening
the lid of the enclosure
