User Manual – Arenal PCS – QA03-SDA Page 30/74
Service Engineer 5 Calibration Settings SERVICE 26
Arenal Engineer 8 Advanced Settings ARENAL ****
Factory 10 Software Settings DEVELOPER ****
4.9.7 Screen Shot
Press this button to make a screen shot in BMP format of the current screen. The file is saved to folders on
the USB per hour. Taking screenshots therefor only works when the USB is present. The folders with the
screenshots can be found on the USB under the folder ‘ScreenCapture’.
4.9.8 Save and Store Data on USB
This icon pops up when user gets into the configuration pages. Pressing this icon will save all settings to the
files on the USB stick.
4.10 Dredging – Reset Production
In the dredging industry operators could determine to calculate the total produced solids during a shift. At
any desired moment, press “Stop Dredging” and the “Start Dredging” at the button with the cross meter.
From that moment the totalizer starts again.
