User Manual – Arenal PCS – QA03-SDA Page 8/74
Interesting! This word indicates that the text that follows contains
comments or interesting
points of information.
1.4 Abbreviations
All abbreviations in the manual are listed here.
QA03‐SDA
QA03‐SMA
Slurry Density Analyzer
Slurry Massflow Analyzer
QT016‐UDT Ultrasonic Density Transmitter. Electronic module to send high voltage pulses to
the probe and receives and analyses returning echo’s. The SDA and SMA
however further analyses these raw values and calculates the SG, Density, TSS
and temperature.
QP015‐UDP
QC000‐QQ
Ultrasonic Density Probe to determine Slurry Density
Connection cable between transmitters or modules to the SDA or SMA
QC014‐UDC Coaxial cable for harsh conditions in mining industry, to connect the UDP with
the UDT
QT656‐TMT Thermal Massflow Transmitter
QP654‐TMP Thermal Massflow Probe
QM132‐IOM
See Chapter 10: IO Module. An Extended IO Module, which offers galvanic
isolated mA inputs and outputs and digital inputs and outputs. The mA signals
have a sensitivity of 16 bits. The module is connected on the base motherboard.
SDA
SMA
See QA03‐SDA
See QA03‐SMA
UDT See QT014‐UDT
UDP See QP015‐UDP
UDC See QC014‐UDC
TMT See QT656‐TMT
TMP See QP654‐TMP
IOM See QM132‐IOM
