Argo Frontier 650 8x8 2021 - Re-Installation of Brake Pads; Re-Installation of Firewall; Emergency;Parking Brake Adjustment

42
To replace the brake pads:
Brake pads are easily replaced by removing the single bolt
securing them within the brake caliper assembly and pulling
each pad up and out of the caliper. See Figure 7-29. Pistons
havetobepushedbackinrst,toallowclearanceforthenew
pads. Slip the new pads into the caliper and install the single
bolt fastener to secure the pads in position. Pump the steering
handle bar a few times to the left and to the right to build up
proper pressure and to locate the pads in the caliper assembly.
Figure 7-29. Removing the brake pads from the brake caliper
To replace the rewall:
1. Positiontherewallinthedrivingcompartment.
2. Slidein thebottomoftherewall rstand routethe
throttle cable through the open area at the steering col-
umn.
3. Pushinthetopofrewallupagainstthetabslocatedon
the left and right hand side of the dash support.
4. Reinstall the six (6) socket head fasteners that secure the
rewall.
Do NOT operate the ARGO with the rewall removed.
7.3.5 EMERGENCY/PARKING BRAKE
CLA
1.Removetherewall.
2. Ensure the parking brake lever is fully up. Figure 7-30
3. Locate the Parking Brake Adjustment Bracket near the
bottom of the transmission. Figure 7-31. Check to ensure
that the brakes are NOT engaged when the Brake Lever is
intheup&oposition.Usinga0.004"feelergaugeslipit
SECTION 7
MAINTENANCE INFORMATION
between the emergency/parking brake pad and brake disc.
Ensure that you push the opposite side pad up against the
brake disc before setting this gap.
12. Check for drag by driving without activating any brakes
for about 100 feet. Stop and check for heat on the brake
discs. They should both be cool (or no hotter than the
beginning of the test). Adjust if necessary.
13.Checktheeectivenessoftheparkingbrakebyparking
the Argo on the steepest hill encountered and by loading
to it’s maximum working load. The parking brake should
hold the Argo from moving.
14.Checktheeectivenessoftheemergencybrakebyac-
tivating it while coasting down a slight grade. The Argo
should come to a controlled stop without pulling left or
right. Re-adjust the brakes if necessary.
15. The emergency/parking brake should be checked for
proper adjustment every 25 hours. Note: Oil on the brake
disc caused by improper chain oiling can permanently
reduce the eectiveness of all brake systems.
Figure 7-30.
Figure 7-31.
