Argox CP-3140 - Fonts, Barcodes, and Graphics Specification

64
Compact Printer Series - User‟s Manual
Max roll capacity(OD):4.5”(114.3mm) Core
size:0.5”(12.7mm) (optional)
Min Length: 0.59“(15mm) for cutter option
Ribbon
Ribbon roll – max OD: 2.6”(67mm)
Ribbon Length: max 300m
Core size – ID: 1”(25.4mm)
Ribbon Width: 1”~4” Wax, Wax/Resin, Resin
(Ribbon wound ink-side out or ink-side in)
Dimensions
L 273mm x W 225mm x H 186mm
Weight
2.1kg
Power Source
Universal Switching Power Supply AC
Input: 100~240V,1.8A, 50-60Hz, DC
Output: 60W Max.24V 2.4A
Universal
Switching Power
Supply AC Input:
100~240V,1.5A,
50-60Hz,
DC Output: 24V,
2.91A Typical,
70W Max.
Operation
Environment
Operation Temperature: 40F~100F (4C~38C), 10% ~
90% non-condensing,
Storage Temperature: -4F~122F (-20C~50C)
Optional Items
Cutter, Stacker, RTC Card, ArgoKee
Agency Listing
CE, FCC, cTUVus, CCC, RoHS
Fonts, Barcodes, and Graphics Specification
The specifications of fonts, bar codes and graphics depends on
the printer emulation. The emulations PPLA, PPLB, and PPLZ are
printer programming languages, through which the host can
communicate with your printer.
