REPLACEMENT OF PARTS
14.164.A_A707en.SM.V1.01.doc ARGUS Medical AG 10.02.04 AS 29 / 38
1. Use the screw with a washer at
these places (torque 1.0 Nm)!
2. Use the screw without a
washer at these places
(torque 1.0 Nm)!
4. Make sure that this part
touches nowhere, oth-
erwise noises may be
generated!
3. Reinstall the door. Make sure
that a washer has been in-
stalled on each side!
6.2.4. Assembling the pump
