EN – 19
Install Throttle Control Lever
1. Secure throttle control lever to handlebar with one
machine screw and flange nut. See Figure 42.
2. Insert cable end into throttle bracket and insert cable
anchor into cable bracket. See Figure 41.
BLADE-BRAKE CLUTCH LEVER
REPLACEMENT
Remove Blade-Brake Clutch Lever
Models 911177, 911189
IMPORTANT: Retain hardware for reinstallation.
1. Place unit in service position. See Service Position on
page 7.
2. Loosen clutch cable adjustment nuts and remove
adjustment barrel from cable bracket. See Figure 43.
To Next Page
