Ariston AURES S 3.5 COM PL User Manual

10
EN
Unit Dimensions: Height 183mm Width 290mm Depth 108mm
Table 2
Power kW Loaded Heating Setting Recomended
Cable Size
Recomended
Fuse Rating
220V 230V 240V
3.5kW 3.5 3.8 4.1 1.5+2.0 kW 2.5/4mm
2
20 amps
4.0kW 4.0 4.3 4.7 1.0+3.0 kW 2.5/4mm
2
20 amps
5.0kW 5.0 5.5 6.0 2.0+3.0 kW 4/6mm
2
25 amps
5.5kW 5.5 6.0 6.5 2.2+3.3 kW 4/6mm
2
25-32 amps
7.0kW 7.0 7.6 8.3 3.0+4.0 kW 6/10mm
2
40 amps
7.7kW 7.7 8.4 9.1 3.0+4.0 kW 6/10mm
2
40 amps
5.5kW 5.5 6.0 6.5 2.2+3.3 kW 4/6mm
2
25-32 amps
• Operating water pressure 0.3-8 BAR (4-116 psi) • Water pressure operating power switch
• Standard 1/2"Ø compression inlet connection • Top-left and right cable entry • Bottom-left water entry
Close cover Steps
ABC
