Ariston AURES S 3.5 COM PL - Installation Diagrams; Up to 6 kW (One Phase); 7 kW to 9.5 kW (One Phase); 5.5 kW to 9.5 kW (Two Phase)

9
EN
Up to 6kW
(One Phase)
7kW to 9.5kW
(One Phase)
Also for 127V up to 5kW
5.5kW to 9.5kW
(Two Phase)
1. Multi-pole switch
2. Terminal block
3. Thermostat
4. Microswitch
5. Switches
6. LED Light
7. Heating elements
8. Pressure switch
INSTALLATION
