Ariston microSYSTEM 15 RFFI

4
1.2.2 Removing the sealed chamber front cover
1. Remove the screws “C” (FIG. 1.6);
2. Lift the sealed chamber front cover from the locating pins
(FIG. 1.7).
FIG. 1.6
C
C
FIG. 1.7
1.2.3 Removing the side panels
1. Remove the four screws “D” for each side panel (FIG.1.8);
2. Pull the panel away from the boiler at the base, then lift the
panel up and remove from the boiler.
D
D
D
FIG. 1.8
