Legend:
1. Hybrid module
2. External unit
3. Outdoor sensor
4. Diverter valve
5. High temperature heating zone
6. Sensys and Sensys Net remote control
7. Filter
8. Anti-freeze cartridge
9. Heat generator
10. Dirt separator fi lter
Legend:
1. Hybrid module
2. External unit
3. Outdoor sensor
4. Diverter valve
5. Cooling zone
6. Sensys and Sensys Net remote control
7. Filter
8. Anti-freeze cartridge
9. Heat generator
10. Dirt separator fi lter
6
2
1
7
8
3
9
10
5
4
6
2
1
7
8
3
9
10
5
4
SCHEME WITH SEPARATE HEATING AND COOLING SYSTEMS (HEATING-MODE OPERATION)
SCHEME WITH SEPARATE HEATING AND COOLING SYSTEMS (COOLING-MODE OPERATION)
